I had been wanting to test the Afflictor Hybrids as well as their fixed-blade broadhead offerings for a while. So, when I finally got my hands on some I was excited to test them out. (If you want to jump straight to the section of the review you are interested in, you can do so by clicking the links below:
Afflictor Hybrid Construction
I have used tested and used other hybrid broadheads on the market, but the Afflictor heads are different than other designs. They have a main cutting tip that’s about 1/8-inch thick, made of 420 stainless steel that is extremely thick and sharp and will not fold over.
They also have a feature they call a “drive key,” that also functions as a bleeder blade that opens up the main blades, but also cuts extra tissue.
Afflictor 1-3/4″ K2 Hybrid vs Afflictor Ultraviolet (Hybrid X Mini) | The differences
On the 1¾-inch Afflictor Hybrid (or, K2 Hybrid as Afflictor calls it), the drive key has little prongs on it. They are designed in such a way that if they hit hard bone, they will shear off by design, so that the head can continue to penetrate. In fact, everything about this head is designed for penetration.
Afflictor also offers a head called the Ultraviolet, that is purple in color (now called the Hybrid X Mini) . At the time of this publication, it is the only purple broadhead on the market.
The Ultraviolet has a little bit different design. The main tip of the Ultraviolet is longer and more swept than the original Afflictor Hybrid. Due to that design, it has a little bit better penetration.
Another difference is that the Ultraviolet has non-shearing drive key that functions as a bleeder blade. So it’s a half-inch wide and will open up the blades and continue to cut tissue.
With the Ultraviolet broadhead, you get a 1¾-inch cut and plus the ½-inch bleeder, for a total of a 2-inch cut.
Afflictor also makes a 1½-inch model of this as well and it also has the ½-inch bleeder, for a total cut of 2 inches.
The Ultravioloet head has a longe tip and more swept design.
Both versions of this broadhead fly extremely well. They are both 5/8-inch thick in profile, which is like most other mechanical heads on the market. The specs and construction are top-notch. They also spin very well in flight.
On impact, the drive key comes down and the blades open. There is also a pretty strong o-ring that keeps the blades from rattling during flight.
The NAP Killzone is my standard for comparison testing, as it’s been around for many years. It’s a really reliable and super strong head. However, it doesn’t penetrate very well, so anything I test should penetrate better than the Killzone.
For comparative purposes, I tested penetration and durability in comparison to the NAP Killzone broadhead.
Penetration Testing | The Setup
If you have seen any of my broadhead tests on mechanicals, you know that when I do comparative tests, I don’t test them on animals. The reason I don’t do this is because they don’t hold any value.
Different bones have different densities and bone geometries. Every animal is different. In addition, shooting angles on animal bone could have varied results, which would not provide good insight into how the broadhead truly performs.
So, I use a uniform medium to simulate animal anatomy as best as I can. I use carpet on the front and the back to simulate animal hide. I also use a rubber foam to simulate tissue and ½-inch plywood in the middle to simulate the bone.
Penetration test using Afflictor Ultraviolet, Afflictor 1-3/4″ Hybrid and NAP Killzone.
Then I use a few more layers of rubber foam toward the end for padding, followed by another 3/8-inch plywood at the end just in case it were to make it through all of that.
I also have a thin sheet of cardboard in the very front to get a visual on how well the heads deploy on impact.
Penetration Test #1
I first tested the Killzone head, followed by the Afflictor 1¾-inch head and the Afflictor Ultraviolet.
In the penetration test, the Ultraviolet out-penetrated the others by a wide margin. Of course, the Ultraviolet it has that more swept initial tip and also has the 1½-inch cut, and that solid drive key. Those factors made all the difference in this penetration test.
Take a look at the Afflictor 1¾-inch cut broadhead. The 1¾ inches plus the ½-inch bleeder provides 2¼ inches of cut. The blades came all the way through the ½-inch plywood after going through the carpet and the rubber mat and the cardboard.
The NAP Killzone tip came through the wood, the blades did not. The NAP has a good, long tip that’s really tough. But the blades didn’t do any cutting on this test. All the broadheads in this test held up well in the penetration test.
Initial Cut Size
When inspecting the opening cut, the Ultraviolet opened 1½ inches from the main blades and then ½-inch from the bleeders and the bleeders stayed intact.
The 1¾-inch Afflictor Hybrid opened 1¾-inch on impact and then had the drive key bleeders cut a ½-inch and those stayed intact as well.
The NAP Killzone advertises a 2-inch cut, and it actually cut a little over two inches (2-1/4 inches).
So, all the heads in this test opened well.
This shows the initial cut size of the Afflictor Ultraviolet and Afflictor 1-3/4″ Hybrid vs. the NAP Killzone.
Penetration Test #2: Angled Shot
In the next test, I performed a steep angled shot.
I first shot the Killzone and it stuck right in. Then, I shot the Afflictor 1¾-inch Hybrid. It stuck in, but angled off a bit. Lastly, I shot the Afflictor Ultraviolet.
In the diagram below, you can see that the Killzone and the Ultraviolet penetrated through the back of the wood. The Killzone point come through the wood but not the blades. The Killzone also broke off at the ferrule and broke my arrow.
The 1¾-inch Hybrid went through all the layers of carpet and foam and cardboard and made a deep cut in the wood, but it skimmed across the top of the plywood.
In the angled shot test, all three heads penetrated, but the Afflictor 1-3/4″ Hybrid slid on impact.
Afflictor Ultraviolet and NAP Killzone penetration through back of the plywood on angled shot penetration test
The NAP Killzone broadhead broke off at the ferrule during the angled shot penetration test.
Penetration Test #3: Afflictor Ultraviolet into 22-gauge steel
In this test I shot the Afflictor Ultraviolet into 22-guage steel, backed with a 3/8-inch sheet of plywood, a ½-inch sheet of plywood, 4 rubber mats and a Rinehart target behind it.
Because I didn’t want to break another arrow, I used the Mammoth Arrow by Bishop Archery, which are guaranteed for life.
The Ultraviolet went through the 22-gauge steel plate and poked through the back of the 3/8-inch board about a ½-inch. The tip held up really well.
The blades of the Ultraviolet not only went through the steel plate, but they opened up as well, which is very impressive.
When I have shot other heads into steel and plywood in this manner, they only hold up when the blades don’t reach the steel plate. But here, the blades held up and even opened up inside of the steel plate. Even the drivel key was still intact.
Ultraviolet penetrating steel/wood and deploying blades.
The tip and blades of Ultraviolet post steel plate test.
BONUS: Afflictor K2 Mini Hybrid Tests
I’ve shot the Afflictor K2 Mini broadheads not only in tests that I perform, but also in the field. I’ve killed turkeys, hogs and deer with these heads and they’ve always performed very well.
The K2 Mini is basically the same as the other hybrids (the Afflictor 1-3/4” Hybrid and the Ultraviolet). The K2 just has a shorter overall profile.
I have shot these at long range and know that they fly very well, so I did not put them through a flight test as I typically do with the other heads.
K2 Mini Up Close
Below you can see the K2 Mini up close. And again, it’s just like their other K2 Hybrid, only it has a shorter ferrule, which is going to aid in flight, since it has less surface area.
The K2 mini has an aluminum ferrule, but in my testing so far, it has done really well. They are quite strong. Of course, everything else is steel.
The Afflictor K2 Mini broadhead with blades in the deployed position.
So let’s put it through the test and see how the Mini performs.
K2 Mini out-of-the-box sharpness test
The K2 Mini was able to cut paper after two strokes of the arrow but not after the third.
The K2 Mini was able to cut paper after three strokes of the carbon shaft of an arrow.
Penetration test of K2 Mini
I shot the K2 Mini through a rubber mat, backed with 1/2″ MDF and ballistic gel. The results are below.
The K2 Mini penetrated in ballistic gel right at 8 inches.
K2 Mini durability testing
I shot the K2 Mini through 1/2″ MDF that was backed by a Rinehart target. See below.
The blades and tip of the K2 Mini held up well after going through the MDF and Rinehart target four times. The small drive keys that deploy the blades broke off, but that is by design.
K2 Mini steel plate test
Usually, I don’t do this test with expandable broadheads, but I also shot the K2 Mini into a .22 gauge steel plate because they typically don’t make it through the first time. But, this one made it through the first time just fine. The second shot did some damage. See below.
This was after the second shot through the steel plate. You can see that it got pretty dinged up. The ferrule is in great shape. It lost those drive keys again. Tip is in perfect shape and the blades got a big dinged up there as you can see. So the blades would have to be replaced, but the head could be good to go.
It was pretty impressive for a mechanical like the K2 Mini to make it through the MDF four times and through the steel plate twice.
Final Thoughts on Afflictor Hybrids
In this Afflictors Hybrids broadheads review I learned a lot. I didn’t really know what to expect from these heads. But, I have to say I was impressed. They have a very low profile and will fly really well and shoot accurately.
The Ultraviolet’s penetration was extremely impressive, especially on the angled shot, as they not only penetrated the steel plate and the plywood, but also deployed the blades.
If you are looking for a fool-proof hybrid mechanical head, the Afflictor Hybrids have qualities of a mechanical and a fixed blade and are going to fly like a dart and hold up well so you can kill some big game!
I’ve long enjoyed Afflictor broadheads, whether it’s the Hybrids or the fixed-blade heads. I’ve used all of them in many hunting situations and they’ve always performed really well.
The Afflictor Fixed Blade Head Offerings
In the following review, I’m going to be testing some of the the fixed-blade heads in the Afflictor lineup.
Afflictor Fixed-Blade Broadheads
The Afflictor K2 and EXT fixed-blade broadheads are similar in design, but the K2 has a shorter profile.
There are a lot of good companies in the archery business, and Afflictor is certainly one of them. Afflictor has a passion for testing, they are ethical and they are faith-based.
Now, before testing the fixed blade heads from Afflictor, I was already a big fan of the Afflictor Hybrids. I’ve taken deer, turkey, and hogs with them. They’ve always performed really well. They flight great. They penetrate deep, they hold up well and they inflict a lot of damage in animals.
So, when Afflictor sent me the fixed blade heads, I thought, “Well, I really like the hybrids.” But, then when I started shooting the fixed blade heads, I thought, “Man, I really like these too!”
I first tested the K2 and the EXT models. They’re similar in design, but obviously, they have different specs. (Further down in this review, I also tested the Heavyweight versions of these heads).
An overview of the fixed heads
When I first looked at the fixed blade heads, I thought, “Okay, they’re just like normal 4-blade fixed blade heads.”
And yes, they are, but there are some unique things about them.
First of all, the K2 has a super short, low profile design. That’s why it flies so extremely well.
I would put the K2 up there with any fixed blade head as being the very best flying. There are several that I put in that category that just are top of the food chain in terms of long distance flight. This one is one of those.
The EXT also flies very well, but at super long ranges, it’s not quite as good as the K2, and that’s just because there’s more surface area.
You can see the total length is greater on the EXT heads, and therefore more surface area. That’s why the K2, with less surface area tends to fly better at long distances.
Another unique feature of the K2 is that the blades themselves are extremely thick. They are 420 stainless steel, so they are a decent stainless steel. But beyond that, they are really thick.
The standard for many fixed blade heads is 0.030 or 0.035 inches thick. I have always liked how the QAD Exodus blades are 0.040 inches of thick. Well, the K2 blades are 0.059 inches thick. That’s impressive! (All four of the blades on both the K2 and EXT are 0.059 inches thick).
K2 and EXT tips
This tips of the K2 and EXT are also very unique. It’s not like a chiseled tip on other broadheads. It’s not like a true “cut on contact tip” though it does cut on contact. But it’s really thick. It’s actually double the thickness of the blades themselves. It’s 0.125 inches thick!
With that thickness, what that translates into is two things. First of all, durability. But, secondly, it’s going to make a really thick cut through the deer or animal. And, I found that with all things being equal with penetration, the thicker the blades, the harder it is for that wound channel to close up.
This results in better blood trails.
That’s why these Afflictor fixed blades perform so well for me in the field and have created such good blood trails; it’s the blade thickness.
The tips of the Afflictor K2 and EXT is extremely thick.
A Horizontal blade cross? Yes, and here’s why
Another thing that is unique about these fixed heads is if you look really closely, the top of the cross blades are actually horizontal for a little bit and then at an angle.
This feature is not by accident.
Now, you might look at that and say, “Well, that’s going to impede penetration.”
Actually, what Afflictor found is just the opposite.
The K2 and EXT have a horizontal blade crosssing that actually aids in bone penetration.
In all their testing, the folks at Afflictor weree surprised to see it that sometimes what really happens during penetration seems like it defies the laws of physics.
They found that the penetration through bone has actually improved by having a little bit of horizontal cut because the head is able to breach the bone. It pushes the bone out of the way more effectively with that angle as well.
I was interested to see how it does this in my own testing.
With the extra thick tip and with the cross blades being moved up on both the K2 and the EXT, it allows for a greater FOC. So, compared to other heads that have similar dimensions, these are going to have more weight toward the front end. That’s going to aid in forgiveness in flight and it’s also going to aid in penetration.
The ferrules on the K2 and EXT are aluminum. Now, I’m not typically a big fan of aluminum… unless it’s this kind of aluminum. The aluminum ferrules on these heads are made of 7075 T6 grade aluminum.
So, this aluminum is stronger than many steels. I haven’t had any problems with it in the field. Let’s see how it did in the testing.
For each of my tests, I used my Bowtech SR6 on the comfort setting, set at 72 pounds, 27-inch draw. I used Bishop FOC King Arrows (460 grains), Nockturnal Nocks and FOBs.
What I tested for
Because of the weather at the time of these tests (we were in the middle of a blizzard here in Iowa), I did not go outside to test long range flight.
I’ve already shot the K2 at longer ranges in the field and I know it is absolutely fantastic, the best of the best at longer ranges. I would give it a 10. It flies like at ATAC, Iron Will original, or a Bishop Holy Trinity… very, very good flight.
I would give the EXT a 9. It does really well out to about 60 yards. But, it’s a little more touchy beyond that. I can still pop balloons at 80 yards but I have to really focus on it.
I did, however test for penetration, durability, and edge retention.
Penetration testing of Afflictor fixed blade broadheads
I tested penetration by using a 1/2-inch inch layer of MDF, surrounded by 1/3-inch layers of rubber foam matting. On the back side of that medium is ballistic gel, made by Clear Ballistics. The clear gel allows you to see exactly what the broadhead is doing inside the gel.
I also measured the penetration, so that it can be compared to how other heads penetrate the same medium.
Here, you can see the penetration of the two. And as expected, the one with a smaller cut, penetrated more deeply than the one with a larger cut, though it wasn’t by much. The EXT here at the bottom penetrated 8 and 1/4 inches and the K2 at the top penetrated 7 and 3/4 inches.
Durability and edge retention testing
I shot these heads through a 22-gauge steel plate. In this test, I will shoot through the steel plate as many times as possible (up to 5 times), until the blades really start to get damaged. When the blades start to get significant damage, I stop.
For the purposes of scoring, each time I shoot without them getting significant damage, I give the head 2 points. The maximum a head can receive is 10 points. The maximum is 5 shots.
As for the blades themselves, I shot both the K2 and EXT into the steel plate and examined them after each time. Both heads made it 3 times into the steel plate before the blades began to get pretty mangled.
Here are the holes that the K2 and EXT made in the 22-gauge steel plate. And you can see, the ones at the bottom are by the K2. The ones on the top, the EXT. The K2s really punched a big hole. You can see why they would open up a big hole in an animal. That wound is not going to easily close up. Really, really impressed by that.
The blades were not bent way out of shape, but they were definitely getting nicked up enough to stop shooting. So, three shots through the steel plate at that range is pretty impressive. The blades are replaceable and would need to be replaced. But, they will get a score of 6 because they made it three times into the steel plate.
Notice that the tip is just like brand new. It did not move at all. And that’s what really matters the most when it’s going into an animal. So, I was really impressed with that. And then it was actually the same for the EXT. So, you can see the blades there getting pretty nicked up and you can see those cross blades there getting a little flared out, a little bent out of shape. And again, the tip just pristine.
Both the K2 and EXT are really good heads. For flight, for total cut size, and for damage being inflicted, I go with the K2 but both of them are really good heads.
Actually, in the field, I would say the K2 does even better on animals than it showsin the testing.
The Afflictor K2 and EXT heavyweight fixed heads
In addition to the K2 and EXT, I also tested the Heavyweight versions of these broadheads. All of the heavier Afflictor fixed blade broadheads are stainless steel and they vary in weights from 155 to 200 grains. In my tests on the heavier fixed blade heads, I specifically be testing the 200-grain models.
Here’s a look the Afflictor Heavyweight lineup of their fixed-blade heads.
How the heavier fixed blade heads are different
The heavier versions of the Afflictor EXT and K2 differ from each other, as well as their lighter counterparts…
The tips and ferrules of the heavyweights
One main difference between the EXT heads and the K2 heads is the tip (The EXT tip is also used on the EXT Hybrids and the K2 tip is also used on the K2 Hybrids).
The biggest difference in the heavyweight heads over the 100 and 125-grain models is that the heavyweight versions are all stainless steel. The ferrules are no longer 7075 aluminum as they are in the lighter weight models. Now, they are stainless steel.
For example, the 155-grain model is basically the exact same head as the 125-grain model but with stainless steel ferrule, which adds the extra weight.
The tips on both of these heads are extra thick. By my measurement, it came out to 0.14 inch thick in that leading tip of both.
Now, some people note that the tip on these heads is not super sharp. And, that’s right, it’s not.
But don’t let that fool you in terms of its performance. It’s really about edge-integrity.
The tips on these heads promotes edge straightness, (the lack of chips and dings and bending that affects penetration) and they are really tough, holding a straight edge all the way into an animal. Then, the blades behind them do the cutting.
The tips of the EXT differ from the tips of the K2, but they are both extremely thick.
The heavier heads are basically the same heads as the lighter models, except that they have stainless steel ferrules and weighted washers, which, in addition to larger blades, gives the extra weight.
The bleeders on both the K2 and EXT are very thick.
Blades, bleeders and cutting diameter
I really like the way Afflictor increased the weights of these heavyweight broadheads by beefing up the blades themselves. Very well done.
Some other things you’ll note about the different models is the EXT has a cutting diameter on the main blades of 1-1/4 inches and then the bleeders are 11/16 of an inch.
And then on the K2, the maximum cut 1-1/8 inches and then the bleeders are 1 inch. So, it’s kind of cool that you have different dimensions to choose from based on your setup and what kind of a hole you want to put in the animal.
Some other things that are noteworthy are the main blades on both the EXT and the K2 are both 0.053 inch thick. That’s a thick main blade!
Typically, bleeders are thinner and weaker, but not on these heads. These bleeders are 0.059 inch thick. So really thick bleeders right there.
I’ve taken a number of animals with the 125-grain fixed versions and they all performed really well.
So, as you can see, for many reasons, I was eager to put these heavier weight broadheads to the test.
Heavyweight Afflictor fixed-head penetreation test
I didn’t test the heavyweight heads for all the things that I tested the 125-grain model with, like flight. They are basically the same dimensions (just differing weights), so they’re going to fly the same.
I’ve also already tested them for edge sharpness and edge retention and they did very well.
But, I did test them for penetration and durability. And for that, I’m used the 200-grain version, just because I was curious to see how that heavier weight makes a difference in terms of the penetration and the durability.
So, let’s see how this heavyweight lineup of the EXT and the K2 Fixed-Blade Afflictors performed.
For the penetration test, I shot into a foam mat, backed by ½” MDF and a block of ballistic gel.
Check out the penetration results below:
The K2 200 grain head penetrated 9 inches into the foam mat/MDF/ballistic gel.
The 200-grain K2 penetrated 9 inches. The EXT penetrated 9-1/4 inches.
Durability testing of K2 and EXT
I shot both heads into a .22 gauge steel plate. Both the EXT and the K2 heads really punch a hole, as opposed to “slits” like some other heads make. That’s what I look for in a fixed-blade head. I want something that punches a big hole, because it’s going to be a lot harder to close up that wound channel.
Both heads were impressive in this test, but I give a slight edge (in the way the hole looks) to the K2.
If you look at the heavyweight K2 here, you notice that it really does make a bigger hole. It’s interesting because the heavyweight EXT is a bit wider just by an 1/8 of an inch. But because the bleeders are so wide over here in the K2, man, it just makes a nice big hole. You can see the same type result with the EXT here. The tip and ferrule are in perfect condition, but those blades got a bit nicked up. But very impressive holes and impressive durability.
Now, as for the durability of the heads themselves, they both held up fairly well. Of course, the tips and the ferrules are all in perfect condition. The tip is really durable. You can’t even tell it has been shot into anything, let alone steel.
But, the blades got really nicked up, and that started on the second shot. You could see them start to get nicked up on the first shot and then a little more with each subsequent shot.
Now, they are replaceable blades. Their gradual bevel makes them really sharp, but it also makes them a little prone to a bit of edge bending and nicking when shot into a super hard medium like steel.
Final thoughts on the Afflictor heavyweight fixed heads
So what do you think of the Afflictor Heavyweight K2 and EXT broadheads?
I’ve used them in hunting situations and they perform really well. I’ve been impressed with how beefy these fixed blades are (I especially love the Hybrids).
Like a few other broadhead companies out there, I’ve been so impressed with the Afflictor lineup,
So, check out the score sheets below and see how these things performed, and consider them.
If you’re looking for a little more “oomph” and more FOC, they might be the broadheads for you.
